- Place of Origin: China
- Brand Name: United Asia
- Model Number: c-1
Model | C-1 |
Effective work range | 2500*1260*200mm |
Maximum machining size | 2440*1220*50mm |
Table size | 2440*1220mm |
Loading and discharging speed | 15m/min |
Transmission mode | X/Y rack；Z screw rod |
Table structure | Double-layered word structure |
Spindle power | 6KW |
Speed of spindle | 18000r/min |
travelling speed | 50m/min |
Maximum operating speed | 20m/min |
Drive system | SYNTEC/HCFA |
Working voltage | AC380/3PH/50HZ |
Operation system | SYNTEC/NCStudio/Lnc |
